2 Tph Biomass Briquette Machine Combo
In StockAdditional 18% tax. Final prices are based on customer-specific requirements and accessories.
Biomass Briquetting Press 25mm with Fly Wheels, Crank Shaft, Connecting Rod.
75HP Havells Electric Motor 1440RPM, 50/60HZ, 380V Supply, with Main Pulley & Nylon Belt.
Complete Lubrication System attached 3 HP Havells Electric Motor along with Pump, Oil Filter, 10 HP Feeding Hopper, 3 HP Feeding Conveyor, 3 HP Output Belt Conveyor.
Heat Exchanger System for better cooling for lubricating oil pressure gauge.
Acrylic Doom Cover (Visualize the inner portion of Machine).
Hard Chrome on Piston up to 9 Filler.
Main Die Holder with Die Holder Clamp.
Product Specification
Raw Materials Can be Used:
Groundnut Shell, Saw Dust, Sugarcane Bagasse, Rice Husk, Soya Bean Husk, Mustard Husk, Castor Seed Shell, Cotton Stalk, Cumin Waste, Almond Shell, Macoddana Shell, Jute Waste, Forest Leaves, Napier Grass, and other agricultural waste materials.
Biomass Briquette Machine Combo – Reliable and Efficient Briquette and Pelletizer for Industry
Type: Crank Type
Stroke: 200mm
RPM: 1440
Total Power Requirement: 95HP (71 kW)
Power Consumption: 35-40 Units/PHR
Production Capacity: 800 to 2000 Kg/Hr (Depending on Size, Density, and Quality of Raw Material)
Finished Product Size: Up to 25mm Dia and 90mm
Finished Product Shape: Cylindrical
Finished Product Length: 10 mm to 100 mm
Raw Material Form: 0 to 25mm Size Can Be Used Directly
Complete Foundation Drawing with Foundation Bolts.
Automatic Temperature Siren System with Alarm.
